4800 Electromagnetic Flowmeter

Brand:	Sensor
Product Code:	Sensor
Availability:	100

0 reviews Write a review

Rp0.0
Ex Tax: Rp0.0

Payment Profile

Qty

Description
Reviews (0)

Electromagnetic Flow meter does not have any moving parts, ideal for wastewater applications or any dirty liquids which is conductive or water based, or for applications where low-pressure drop and low maintenance are required. It applies to measure (is fit for the measurement of ) the volume flow of conductive medium including the acid, alkali, salt solution, slurry, pulp, paper pulp, waste water.

Pdf Download

Application

- Water supply systems

- Sewage treatment

- Metallurgy

- Chemical

- Dyeing industry

- Food and beverage

- Papermaking

- Pharmaceutical

Advantages

1. It is the volume flow of liquid and solid two-phase fluid (It is used to measure the conductivity which is greater than 5μs/cm of closed pipeline that and the volume flow of fluid and solid two-phase fluid flow rate.

2. And it is not affected by the temperature of the liquid, viscosity, density, pressure, liquid-solid composition, conductivity of liquid. It has high accuracy and stable working ability.

3. It can be used to measure the fluid medium of other conductive liquid or liquid-solid two-phase flow after the calibration just ordinary water without any additional calibration.

Technical Data

Item	Technical parameter
Main Power	AC220V 50HZ/DC24V/DC12V/3.3V battery power supply
Power Consumption	<15W (Supporting power consumption with sensors)
Display and Buttons	Display in Chinese and English, can display instantaneous flow, accumulated flow and alarm display (excitation open circuit alarm, empty pipe alarm, flow over limit alarm). Four membrane touch switches for data setting
Counter	Forward total, reverse total

Ouput Signal

Analog Output	- Two-way, fully isolated 0~10mA/4~20mA - Load resistance: 0~1.5kΩ when 0~10mA; 0~750Ω when 4~20mA
Frquency Output	Forward and reverse flow output, the upper limit of output frequency can be set within 1~5000Hz. Open collector bidirectional output of transistor with photoelectric isolation. The external power supply is not greater than 35V, and the maximum current of the collector when it is turned on is 50mA
Alarm Output	Two-way open collector alarm output with photoelectric isolation transistor. The external power supply is not greater than 35V, and the maximum current of the collector when it is turned on is 250mA. Alarm status: fluid empty pipe, excitation disconnection, flow overrun
Pulse Output	Forward and reverse flow output, the output pulse upper limit can reach 5000CP/S. Pulse equivalent is 0.0001~1.0m³/P. The pulse width is automatically set to 20ms or square wave. Open collector output of transistor with photoelectric isolation. The external power supply is not greater than 35V, and the maximum current of the collector when conducting is 50mA

Mathcing Accuracy	0.5%
Damping time constant	Continuous variable from 0~100s (90%) time grading optional
Communication	Optional RS232C or RS485 serial communication interface, HART communication protocol
Loss of power	The internal design of the instrument has a power-off clock, which can store 16 power-off records (10 years) (need to be customized)
Protection class	IP65
Explosion-proof mark	Ex d ia [ia Ga] q IIC T6 Gb
