Description

• 1 EZO™ Universal Flow Meter Totalizer Circuit

• 1 1/2″ Female NPT Flow Meter – 5.7 L / min to 75.70 L / min

• 2 1/2″ Male NPT Connectors

• 1 Flow Connector Board (soldering required)

• 1 80 Mesh stainless steel pre-filter (178 microns)

• Food Safe

• Gasoline Safe

• Diesel Safe

• Kerosene Safe

• Reads flow rate per second, minute, hour and total flow.

• Works with any off the shelf pulsed DC flow meter regardless of manufacture

• Works with any DC pulse per volume flow meter

• Works with any DC pulse frequency to volume flow meter

• Programmable with up to 16 integer or floating point K factors

• On the fly linear interpretation between K factors for maximum accuracy

• Visual display indicating real-time turbine rotation

• 1K, 10k or 100k on-board pull-up or pull-down resistors (for flow meters that require external pull-up or pull-down)

• Comes pre-programmed with 4 different Atlas Scientific flow meters

• Data format is ASCII

Data Protocol

• UART asynchronous serial connectivity

• (RX/TX voltage swing 0-VCC)

• Operating voltage: 3.3V to 5

Sleep Mode Power Consumption

• 2.1mA at 3.3V

Download:

https://www.atlas-scientific.com/files/flow_EZO_Datasheet.pdf

https://www.atlas-scientific.com/files/1-2_flow_datasheet.pdf

https://www.atlas-scientific.com/files/ezo-flow-wiringdiagram.pdf

https://www.atlas-scientific.com/files/Arduino-Uno-flow-sample-code.pdf
