HR683 Guided Wave Radar Level Sensor

Brand:	Sensor
Product Code:	Sensor
Availability:	100

0 reviews Write a review

Rp0.0
Ex Tax: Rp0.0

Qty

Description
Reviews (0)

Guide wave radar level sensor is a non-contact, microprocessor controlled, easy to install and maintain digital level instrument,to realize the antenna to the surface of medium distance measurement.

Pdf Download

Application

- Solid Powder - Cement silo Powder - Ash power measure - Solid oil

Advantages

1. Guided Wave Radar Level Meter is suitable for a variety of complex conditions and applications. Such as: high temperature, high pressure and low dielectric constant media. Pulsed work

2. Guided wave radar level instruments transmit power is very low, can be installed in a variety of metals, non-metallic container, no harm to humans and the environment.

Technical Data

Suitable for Medium	Solid powder
Explosion-proof Grade	Exia IIC T6 Ga/Exd ia IIC T6 Gb
Measuring Range	20m
Frequency	500MHz-1.8GHz
Antenna	Double cable type antenna
Accuracy	±10mm
Process Temperature	（-40～150）℃
Process pressure	（-0.1～2）MPa
Signal output:	（4～20）mA/HART
The Scene Display	Four LCD/Can be programmed
Power Source	Two-wire (DC24V) ;Four-wire（DC24V/AC220V）
Shell	Aluminum /Plastic
Connection	Flange (optional) / Thread
