HPT621 Multipurpose capacitance level sensor are designed for liquid level measurements where the levels are lower than 3 meter, 316 stainless steel allows the transmitters to be suitable for harsh environments and various measuring medium.

Pdf Download

Application

- Fleet management

- GPRS tracking for trucks

- Water/Fuel/Diesel tank level monitoring

- Pharmaceutical Industry

Advantages

1. Precise linear and temperature compensation

2. Support local ZERO and SPAN calibration

3. Max 300 Degree C High Temp Liquid level measurement

4. Up to 0.01mm resolution, 10mm Bottom blind Zone

5. Simple installation without any settings

6. Sensitivity and hysteresis fluently adjustable

Technical Data

Range	0 to 100mm 0 to 3000mm
Output	4~20mA,0~5V;Digital RS485
Accuracy	≤ ±1.0%F.S(Typical);≤ ±0.5%F.S(by customized)
Probe Diameter	Φ16 mm (Typical); Φ12 mm (Customized)
Blind Zone	10mm
Stability	Standard: 0.1%F.S/year, Max: 0.15%F.S/year
Medium working Temp	-30°C to 80°C Standard , -40°C~300°C by customized.
Materials of probe	304/316 stainless steel with PTFE/brass
Power supply	11Vdc~33Vdc
Pressure port	G1/2＂,M20*1.5 male,Flange by customized
With adjustable Zero and Span automatically
Certificate	CE,ExiaII CT6 Ga ,ATEX,RoHS
Connection	Fixed cable
